Description
A full set of Arduino Line Following robot assembly kit (DIY) with AA batteries for Arduino enthusiasts.
No soldering is required as it comes pre-soldered for two DC gear motors and one power on/off switch, unless there was an issue during transportation.
We provide a step-by-step installation guide, making it easy to build an line following robot by following our guidelines precisely.
Demo
Specification
Chasis Dimension
~ 215mm x 156mm
Motor Working Voltage
DC3V ~ 6V
Packing List
Arduino Uno Compatible (CH340)
1pcs
Arduino Uno USB Cable
1pcs
L298N Motor Driver Boar
1pcs
IR Line Tracking Sensor
2pcs
Power Exention Board
1pcs
AA Non-rechargable batteries
4pcs (*Note: Last for 10 ~ 20minute ONLY)
Standoff (metal)
4pcs (for Castor)
Standoff (plastic)
9pcs (for Uno board and L298 Motor Driver board...)
Female to Female Jumper wires 10cm
15pcs
Female to Female Jumper wires 20cm
10pcs
Male to Female Jumper wires 20cm
10pcs
Male to Male Jumper wires 20cm
3pcs
Wiring For Line Following Robot Car
Download
1 Arduino Line Following Robot Car Demo Code
2 Installation Manual
